Included Components : Boost Converter Module Xl6009
Product Features :
Robotbanao XL6009 module is a non-isolated step-up power converter module having the feature to efficiently adjust output voltage. It converts input voltage of 5-32V DC to an output voltage of 4-38V DC.
Non-isolated boost converter | Has a non-synchronous rectifier | Small and Handy voltage regulator module | Input reverse polarity protection | Built-in output short protection function
Dimensions: LxWxH:43x21x14mm
The XL6009 Step-up module is a DC-DC non-isolated boost module can be used to convert 5V-32V DC input voltage to an output voltage of 4V-38V DC. It has an efficiency rate of up to 94%. Its high switching frequency allows the usage of small capacity filters for better results. This also produces smaller ripples.
High switching frequency 400KHz, can use a small-capacity filter capacitors that can achieve very good results, the ripple smaller and smaller. (LM2577 frequency only 50KHz) Input Voltage (V):3 to 32 | Input Current(A):4 | Output Voltage(V):5 ~ 35 | Output Ripple(mV):50 | Efficiency:94% | Switching Frequency(KHz):400 | Load Regulation:?0.5% | Voltage Regulation:?0.5% || Pins: IN+ input positive | IN- input negative | OUT+ output positive | OUT- output negative
