Mechanical Stage: Rectangular stage size 135 x 124mm, X/Y travel range 76mm x 50mm. Low drive movement controls, single specimen holder.
Condenser: Sub-stage Abbe condenser NA 1.25 with aspheric lens. Iris diaphragm with snap-in frosted white filter. Rack and pinion movements on metal guides.
Focusing: Co-axial coarse and fine focusing on ball drive system for smooth operation. Fine drive movement 0.2mm/rotation.
Illumination: LED illumination with variable illumination control. Up to 100,000 hours of LED life. Rechargeable Dry Battery Provide 6-8 Hours Battery Backup incase of electricity failure.
Electrical: Universal input 100V-240V AC, 50/60Hz. Built in voltage stabilizer.
