Cables By gofanco

• 328FT HDMI EXTENSION With a single CAT6/7 cable, you can easily extend HDMI audio/video signals for up to 328ft. Direct 1-to-1 connection, 1-to-many through Gigabit network switches. Additional receivers (part# HD20Ext1xN-RX) are sold separately
• NETWORK DISTRIBUTION Connect up to 30 receivers per transmitter. 1-to-many configuration through 1) Unmanaged/Dedicated Gigabit switches, 2) Smart Gigabit switches with VLAN isolating video/audio traffic from the rest of the network. Many-to-many configuration is also supported via VLAN setups. Each VLAN can only accommodate 1 transmitter (TX). *Note: Home routers are not recommended
• VIDEO RESOLUTIONS & AUDIO Supports up to 4K @60Hz, 2K (2560x1440 @60Hz, 2560x1600 @60Hz), 1080p, 1920x1200, 720p. Supports 2-channel PCM audio. *Note: HDR/Dolby Vision/HLG are not supported
• ADVANCED FEATURES HDMI Loopout, IR extension, RS232 pass-through, firmware upgradable, lightning/surge/ESD protection
• SIMPLE INSTALLATION No software is required. Surface mountable metal housing; FCC, CE & RoHS compliant. Our products are backed with a 1-year limited warranty and experienced tech support team in Silicon Valley. If you have any questions or concerns, visit our gofanco website or click on our name in the buy box and select \"Ask a Question\"

• COMPLETE KIT Includes 1 Transmitter & 4 Receivers. Extend and split one HDMI source to four CAT5e/6/7 & one HDMI outputs simultaneously at near zero latency
• HDMI LOSSLESS TRANSMISSION Extends HDMI audio/video signals to synchronous output video display(s), is as fluent as direct connection; Supports up to 50m (165ft) at 1080p@60Hz with CAT5e/6/7 and surround sound up to 7.1-channel digital audio. HDCP 1.4 compliant
• HDMI LOOP-OUT Additional HDMI output on the Transmitter to connect to a local display for monitoring or cascade HDMI signals to 4 layers; Easy-to-follow EDID configurations
• POWER OVER CABLE (PoC) Allows 1 TX power adapter to power all RX't over CAT cables; Supports 1-way IR extension to control a source device from the TV side
• SIMPLE INSTALLATION No driver required; Surface-mountable metal housing. FCC, CE and RoHS compliant. Our products are backed with a 1-year limited warranty and experienced tech support team in Silicon Valley. If you have any questions or concerns, visit our gofanco website or click on our name in the buy box and select \"Ask a Question\"

• 395FT HDMI EXTENSION With a single Cat5e/6 cable, you can easily extend HDMI audio/video signals for up to 395ft. Direct 1-to-1 connection, 1-to-many through Gigabit network switches. Additional receivers (part# HDbitTPRO-RX) are sold separately
• NETWORK DISTRIBUTION Connect up to 30 receivers per transmitter. Direct 1-to-1 connection, 1-to-many configuration through 1) Unmanaged/Dedicated Gigabit switches, 2) Smart Gigabit switches with VLAN to segregate video traffic from the rest of the LAN. Many-to-many configuration is also supported via VLAN setups. Note that each VLAN can only accommodate 1 transmitter (TX). We recommend gofanco 24-port video Ethernet switch (EthSwitch24P-2, B085DD9GG4). *Note: Home routers are not recommended
• LOW BANDWIDTH USAGE: Support 1080p Full HD resolution; supports 480i/480p @60Hz, 576i/576p @50Hz, 720p @50/60Hz, 1080i/1080p @50/60Hz; Auto adjustment for different cable lengths to produce the best video/audio experience. Supports 2-channel Stereo Audio. We recommend using high performance pure COPPER gofanco CAT6 cables to ensure reliable performance: Search CAT6UTP-100(B07PB3R8BK)/CAT6UTP-150(B07P6TDMLH) on Amazon.
• HDMI LOOPOUT - HDMI Transmitter is equipped with 2 port HDMI splitter; Additional HDMI output on the Transmitter to connect to a local display for monitoring. Supports IR extension, allowing source device to recognize remote commands. **NOTE: If audio does not pass through while connected to an HDMI 2.0 port, turn off HDMI 2.0 features to that port or switch to an HDMI 1.4 port
• SIMPLE INSTALLATION - No driver required; Sturdy metal enclosure provides durability and minimizes EMI/RFI noise interference. FCC, CE & RoHS compliant. Our products are backed with a 1-year limited warranty and experienced tech support team in Silicon Valley. Please click on gofanco in the buy box and select ?Ask a Question if you have any questions or concerns.

• IP BASED EXTENSION Supports One-to-One direct connection, or One-to-Many, or Many-to-Many via CAT5e/6/7 cables to extend HDMI signals through Gigabit Ethernet switches, for up to 394ft (120m) at 1080p@60Hz. *Important Note*: This kit HDExtIPv2 (version 2.0) is ONLY compatible version 2.0 Transmitters (HDExtIPv2-TX) and Receivers (HDExtIPv2-RX)
• SCALABLE MATRIX Allows up to 40 TX/RX combined units (5 TX't max) over IP networks. Choose and broadcast any topology of Transmitters and Receivers to create a large-scale Matrix. *Note: Dedicated IGMP Gigabit Switch is recommended for best performance and reliability
• 3 CONTROL OPTIONS IR remote, push buttons, and PC control via software between the sources and displays
• ADDITIONAL FEATURES HDMI loopout on the TX for a local display; IR extension to control the HDMI source device at a remote location; and RS-232 extension
• SIMPLE INSTALLATION No driver required; Surface mountable metal housing. FCC, CE & RoHS compliant. Our products are backed with a 1-year limited warranty and experienced tech support team in Silicon Valley. Please click on gofanco in the buy box and select ?Ask a Question if you have any questions or concerns
