GEE Enterprises Classic Plane Table with Accessories Survey Set

By Brand : GEES

Avg Customer Reviews :

Product Description :

Plane Table with Aluminum Tripod Stand Standard A plane table is a device used in surveying and related disciplines to provide a solid and level surface on which to make field drawings, charts and maps. In use, a plane table is set over a point and brought to precise horizontal level. A drawing sheet is attached to the surface and an alidade is used to sight objects of interest. The alidade, in modern examples of the instrument a rule with a sight, can then be used to construct a line on the drawing that is in the direction of the object of interest. By using the alidade as a surveying level, information on the topography of the site can be directly recorded on the drawing as elevations. Distances to the objects can be measured directly Plane Table Set consist of 1. Plane Table Board Size 60x75x16 mm Plate 100 mm 2. Plane Table Metal Fitting Aluminum 100 mm Dia. With Brass Rod & Fittings 2. Wooden Tripod Stand Legs 3. Alidade 45 cm Standard Type. 4. Plumb Bob Metal 5. Plumbing Fork Aluminum 6. Trough Magnetic Compass Brass Stick on Dial 7. Engineers Spirit Level metal 8. Drawing Board Clip Set Package 2 in Numbers Dimensions: - Packing 1 75x60x3 cm Packing 2 155x15x15 cm Weight: - 1300 gram

Product Details :

Manufacturer : ?GEE Enterprises
Item part number : ?GEE123
Product Dimensions : ?50 x 50 x 50 cm
ASIN : ?B09C5LR7LW

Product Features :

Plane Table with Aluminum Tripod Stand Standard
A plane table is a device used in surveying and related disciplines to provide a solid and level surface on which to make field drawings, charts and maps.
In use, a plane table is set over a point and brought to precise horizontal level. A drawing sheet is attached to the surface and an alidade is used to sight objects of interest. The alidade, in modern examples of the instrument a rule with a sight, can then be used to construct a line on the drawing that is in the direction of the object of interest.
By using the alidade as a surveying level, information on the topography of the site can be directly recorded on the drawing as elevations. Distances to the objects can be measured directly
