Motherboard By Digilent

• Zybo Z7 comes in two APSoC variants: Zybo Z7-10 features Xilinx XC7Z010-1CLG400C. Zybo Z7-20 features the larger Xilinx XC7Z020-1CLG400C. Either variant also has the option to add the SDSoC voucher.
• A feature-rich, ready-to-use embedded software and digital circuit development board with a rich set of multimedia and connectivity peripherals to create a formidable single-board computer
• Built around the Xilinx Zynq-7000 AP SoC, with 650MHz dual-core Cortex-A9 processor and DDR3 memory controller with 8 DMA channels
• On board user interfaces include 6 push buttons, 4 slide switches, 5 LEDs, 2 RGB LEDs, and more
• Expansion opportunities with six Pmod connector ports, over 30 FPGA I/O, four Analog capable 0-1.0V differential pairs to XADC, and more

• Arty Z7 comes in two FPGA variants: Arty Z7-10 features Xilinx XC7Z010-1CLG400C. Arty Z7-20 features the larger Xilinx XC7Z020-1CLG400C.
• Program on board, over JTAG, or boot with a microSD card
• Includes HDMI sink port (input), HDMI source port (output), PWM driven mono audio output, and a variety of user interfaces
• Expansion opportunities with a dual row chipKIT/Arduino connector and two Pmod host ports
• Free software with Vivado Design Suite (WebPACK Edition) and Peta Linux references on the Digilent GitHub

• Arty A7 comes in two FPGA variants: Arty A7-35T features Xilinx XC7A35TICSG324-1L. Arty A7-100T features the larger Xilinx XC7A100TCSG324-1.
• Internal clock speeds exceeding 450MHz, On-chip analog-to-digital converter (XADC), Programmable over JTAG and Quad-SPI Flash
• 256MB DDR3L with a 16-bit bus @ 667MHz, 16MB Quad-SPI Flash, USB-JTAG Programming circuitry, Powered from USB or any 7V-15V source
• 10/100 Mbps Ethernet, USB-UART Bridge
• 4 Switches, 4 Buttons, 1 Reset Button, 4 LEDs, 4 RGB LEDs, 4 Pmod connectors, shield connector

• Dimension- 8.1x12.7x3cm
• Fpga board
• Width- 12.7cm
